Evaluation Kit for the i.MX 8M Plus Applications Processor

8MPLUSLPD4-EVK

滚动图片以放大

The i.MX 8M Plus EVK provides a platform for comprehensive evaluation of the i.MX 8M Plus Quad/Dual and i.MX 8M Plus QuadLite applications processors. It delivers high performance with power efficiency, machine learning and voice and vision capabilities, advanced multimedia interfaces and Wi-Fi/BT for connectivity out-of-the box.

The two-board solution consists of a compact 2.3”x2.3” compute module and a larger base board that brings out the broad connectivity that is needed for product evaluation. The compute module is a proven, compact reference to accelerate your own design.

产品详情

选择区域:

Features

Processor

  • i.MX 8M Plus Quad applications processor
  • 4x Arm® Cortex-A53 up to 1.8 GHz
  • 1x Arm® Cortex-M7 up to 800 MHz
  • Cadence® Tensilica® HiFi4 DSP up to 800 MHz
  • Neural Processing Unit

Memory

  • 6 GB LPDDR4
  • 32 GB eMMC 5.1
  • 32 MB QSPI NOR

Display and Camera Interfaces

  • 1x MIPI-DSI interface (Mini-SAS connector)
  • 1x LVDS interface (Mini-SAS connector)
  • 2x MIPI-CSI interfaces (Mini-SAS connector)
  • 1x HDMI 2.0a connector with eARC

Wireless

  • Azurewave AW-CM276MA-07H 802.11b/g/n/ac, 2x2 MIMO, BT4.2

Audio

  • Audio DAC
  • Microphone/headphone jacks

Connectivity

  • 2x 10/100/1000 Ethernet port (1x w/ TSN)
  • USB 3.0 Type C for Power
  • USB 3.0 Type A
  • USB 3.0 Type C
  • PCIe M.2 interface
  • 2x CAN FD DB9 Female connectors

Debug

  • JTAG Connector

Tools & OS support

  • Linux
  • Android
  • FreeRTOS

支持的器件


Supported Devices

Processors and Microcontrollers

i.MX 8 Processors
  • IMX8MPLUS :i.MX 8M Plus – Arm® Cortex®-A53, Machine Learning, Vision, Multimedia and Industrial IoT

购买选项

8MPLUSLPD4-EVK-Image

点击展开

  • 8MPLUSLPD4-EVK

  • Evaluation Kit for the i.MX 8M Plus Applications Processor.

  • Kit contains:

    • i.MX 8M Plus CPU module​
    • Base board ​
    • USB 3.0 to Type C cable.​
    • USB A to micro B cable​
    • USB Type C power supply
