i.MX RT1180: Crossover MCU with TSN Switch and EdgeLock®
i.MX RT1180 Crossover MCUs are dual-core, real-time microcontrollers (MCUs) featuring an Arm® Cortex®-M7 and Arm® Cortex®M33 for high performance and real-time functionality. The i.MX RT1180 includes an integrated Gbps time-sensitive networking (TSN) switch and EtherCAT SubDevice Controller making it ideal for industrial applications.
The i.MX RT1180 CM7 operates at up to 800 MHz and the Arm Cortex-M33 up to 300 MHz with 1.5 MB on-chip RAM. The family supports multiple protocols, bridging communications between real-time Ethernet and Industry 4.0 systems. The i.MX RT1180 offers advanced security with the integrated EdgeLock® Secure Enclave.
The i.MX RT1180 family is supported by the MCUXpresso developer experience, which includes an SDK, a choice of IDEs and secure provisioning and configuration tools to enable rapid development.
产品详情
Features
Multicore Processing
- Arm Cortex-M7 at 800 MHz and Arm Cortex-M33 up to 300 MHz
- Optional: single core Arm Cortex-M33
Software and Tools
-
MCUXpresso developer experience
- Selection of IDE choices
- Pin, clock, peripheral, security and memory config tools
- Security programming and provisioning tools
- Software development kit (SDK)
- Zephyr RTOS support
Networking
- First real-time microcontroller (MCU) with an integrated Gbps time-sensitive network (TSN) switch supporting multiple protocols bridging communications between existing systems and Industry 4.0
- Real-time industrial Ethernet protocols such as Profinet, Ethernet/IP, EtherCAT, CC-Link IE Field, HSR and more
- Latest generation of TSN standards compliant to IEC 60802 for industrial automation
- TSN based protocols such as OPC UA Pub-Sub, Profinet over TSN and CC-Link IE TSN
- Up to 5 Gbps ports including 4x ports on the TSN switch (Layer 2) and 1x port on the TSN endpoint controller
- L2 management with advanced flow control features including port counters, filters and more
Advanced Security
- First crossover MCU with an integrated EdgeLock® Secure Enclave
- Preconfigured, self-managed, autonomous security subsystem, easing complexity of implementing robust, system-wide security for networked, industrial IoT applications
- Providing component level foundation for IEC 62443 system compliance
- Root of trust requirements in complex networked systems with secure boot, secure key mechanism and high performance crypto
- System-level physical tamper monitoring with secure RTC and 10 tamper pins
On-Chip Memory
- Up to 1.5 MB SRAM (ECC protected) with 512 KB of TCM for Arm Cortex-M7 and 256 KB of TCM for Arm Cortex-M33
Analog
- High-speed 16-bit analog to digital converters
- Advanced timer/PWM and delta-sigma demodulators
Temperature and Qualifications
- Robust extended industrial qualification (-40 °C to 125 °C)
Packaging
- 289 MAPBGA, 14 x 14 mm, 0.8 mm pitch
- 144 MAPBGA, 10 x10 mm, 0.8 mm pitch
