QorIQ® Layerscape 2088A和2048A多核通信处理器

LS2088A 正常供应

点击播放视频

QorIQ® LS2系列处理器提供前所未有的性能和集成，为实现更智能、更强大的未来网络创造了条件。8核QorIQ LS2088A和4核LS2048A多核处理器配备Arm® Cortex®- A72内核，带有先进的高性能数据通路和网络外设接口，适用于网络、电信/数据通信、无线基础设施、军事和航空航天应用。

新一代数据通路架构与强大的软件工具包相结合，提供更高程度的硬件抽象，让软件开发更加快捷简单。

这种组合在软件程序员熟知的Linux®环境中实现了易用性与高性能处理之间的平衡。客户可以充分利用底层硬件，轻松适应网络更改，实现对网络的实时“软”控制。

框图

LS2088A Processor Block Diagram

LS2088A Processor Block Diagram
获取框图PDF

特征

内核复合体

  • 8个64位Cortex-A72 CPU
    • 高达2 GHz
    • 每组的两个内核共享一个1 MB的L2缓存
  • 1 MB L3平台缓存
  • 两个64位DDR4 SDRAM存储控制器
    • 支持ECC和交错存取功能
    • 高达2.1 GT/s

网络元件

  • 线速I/O处理器，具有以下特点：
    • 8x 10 GbE
    • 8x 1 GbE
    • 在以太网接口上实现L2交换
    • XAUI/XFI/KR和SGMII
    • MACSec，最多4个1/10 Gb以太网
  • 两个SATA 3.0
  • 4x PCIe Gen 3控制器
  • SR-IOV支持，根复合体

加速器和存储器控制

  • 加速的I/O处理(AIOP)，高达20 Gb/s的数据包处理速度
  • 20 Gb/s SEC加密加速
  • 10 Gb/s模式匹配引擎
  • 20 Gb/s数据压缩引擎
  • 一个辅助32位DDR4存储控制器，提高数据包处理层的速度，最高可达到1.6 GT/s
  • 4 PCIe控制器(Gen3)，支持1x8、4x4、4x2、4x1通道配置

基本外设和互连

  • 支持硬件虚拟化和分区执行
  • 实施可信架构结合TrustZone®
    • 服务处理器(SP)提供预引导初始化和安全引导功能
  • 2x USB 3.0 (带物理层)
  • 增强型安全数字主设备控制器
  • 串行外设接口(SPI)控制器
  • 四路串行外设接口(QSPI)控制器
  • 4个I2C控制器
  • 两个DUART
  • 支持NAND与NOR闪存的集成闪存控制器(IFC 2.0)
