NXP emWin Libraries

EMWIN-GRAPHICS-LIBRARY

滚动图片以放大

NXP has partnered with SEGGER Microcontroller to offer high performance embedded graphics libraries in binary form for free commercial use with any Arm Cortex-M microcontrollers from NXP. The emWin graphics library for NXP MCUs includes the emWin BASE package, plus additional modules for anti-aliasing, memory devices, multi-touch, and more. Full access to SEGGER’s AppWizard is also included, making the creating of highly efficient and high quality GUIs simple. emWin is integrated into the MCUXpresso SDK packages for several of NXP’s microcontrollers, allowing easy evaluation and migration into your product design. Pre-compiled libraries for products are also available from the Downloads section of this page.

SEGGER offers emWin source licensing options, with special pricing for NXP customers when upgrading from the NXP emWin library to the full SEGGER emWin solution.

软件详情

选择区域:

Features

  • Full access to AppWizard — SEGGER's GUI development tool for creating complete, ready-to-run applications
  • Support for anti-aliasing, alpha blending, and animated sprites and cursors
  • Analog touchscreen and mouse support
  • Multi-layer and multi-display support
  • Memory device module for flicker-free animation
  • Wide range of pre-defined widgets (buttons, sliders, graphs, etc.)
  • Complete set of development tools: GUIBuilder for creating basic UI layouts, bitmap converter, font converter, simulator, and more
  • Window manager for hierarchical window structure
  • Support for black and white, grayscale, and color displays with direct and indirect interfaces
  • VNC server support with file transfer
  • Windows-based simulation environment

Boards supported by MCUXpresso SDK

The NXP emWin graphics library is included as an optional software component in the MCUXpresso SDK. NXP recommends that this library be downloaded using the MCUXpresso SDK Builder for new designs with any of the following platforms:

For all other Cortex-M0, M3, M4, and M7, please download the standalone NXP emWin graphics library. (see downloads tab)

下载

筛选

1-5 / 35 下载

  • BSP、驱动程序和中间件

    MCUXpresso SDK - SDK Builder

    EXTERNAL版本 1.0Mar 2, 2017 13:05:00MCUXPRESSO-SDK
    下载
  • 库

    NXP emWin v6.10f Libraries for Cortex-M0, M3, M4, M7, M33 MCUs

    ZIP版本 0Mar 11, 2020 11:44:0076.6 MBemWin_6.10f_libraries
    请登录
    下载
  • 库

    NXP emWin v5.50g Libraries for Cortex-M0, M3, M4, M7, M33 MCUs

    ZIP版本 0Oct 1, 2019 12:15:0023.7 MBemWin_libraries_5.50g
    下载
  • 库

    NXP emwin v6.16c Libraries for Cortex-M0, M3, M4, M7, M33 MCUs

    ZIP版本 6.16cAug 4, 2021 08:58:0031.9 MBEMWIN_6.16C_LIBRARIES
    请登录
    下载
  • 库

    NXP emWin v6.14d Libraries for Cortex-M0, M3, M4, M7, M33 MCUs

    ZIP版本 0Oct 15, 2020 15:44:0030.2 MBEMWIN_6.14D_LIBRARIES
    请登录
    下载
