产品详情

框图

SEN-SPI-BOX结构框图

获取框图PDF

支持的器件

传感器

运动传感器

MMA69xxKQ: SPI，±3.5g或±5.0g，XY轴，低重力加速度，数字惯性传感器

特征

Microcontroller (MCU)

MK64FN1M0VLQ12

Connectivity

USB
microSD card

Content

1xUSB Type-B Cable
1x Beagle Ribbon Cable (10-pin)
1x NXP MDI Ribbon Cable (16-pin)
1x Debug Cable (10-pin)
1x 8GB micro SD card
1x uSd to PC adapter

Supported voltages

Support 3.3 V and 5 V device
Auxiliary supply 10.5 V or 13.5 V

Software

Fully supported by the NXP FFV Tool software

Supported Sensor

FXLS90xxx
FXLS93xxx (requires SEN-PSI5-ADAPTER)
MMA69xx
FXLS8962

购买选项

点击展开

SEN-SPI-BOX
Evaluation Tool for Automotive Sensors.
1块汽车传感器插座板(SEN-GEN6-SKT)
- 一根USB A型USB电缆
- 一根恩智浦MDI带状电缆（16引脚）
- 一根Beagle带状电缆（10引脚）
- 一根调试电缆
- 一个8 GB microSD卡
- 一个microSD到PC适配器

CNY3,469.15
数量为 1
- 供货情况: 缺货

从恩智浦处购买从分销商处购买

Distributor Name	地区	库存	库存日期

Upon selection of a preferred distributor, you will be directed to their web site to place and service your order. Please be aware that distributors are independent businesses and set their own prices, terms and conditions of sale. NXP makes no representations or warranties, express or implied, about distributors, or the prices, terms and conditions of sale agreed upon by you and any distributor.

点击展开

SEN-DSI3-ADAPTER
Evaluation Tool for Automotive Sensors.
- 1x SEN-DSI3-适配器板
- 2x DSI3电缆

CNY743.39
数量为 1
- 供货情况: 有货
- 库存: 1
- 运单: 正常情况下 1-2个工作日内发货

从恩智浦处购买从分销商处购买

Distributor Name	地区	库存	库存日期

Upon selection of a preferred distributor, you will be directed to their web site to place and service your order. Please be aware that distributors are independent businesses and set their own prices, terms and conditions of sale. NXP makes no representations or warranties, express or implied, about distributors, or the prices, terms and conditions of sale agreed upon by you and any distributor.

点击展开

SEN-PSI5-ADAPTER
Evaluation Tool for Automotive Sensors.
- 1x SEN-PSI5-适配器板
- 2x DSI3电缆

CNY743.39
数量为 1
- 供货情况: 缺货

从恩智浦处购买从分销商处购买

Distributor Name	地区	库存	库存日期

Upon selection of a preferred distributor, you will be directed to their web site to place and service your order. Please be aware that distributors are independent businesses and set their own prices, terms and conditions of sale. NXP makes no representations or warranties, express or implied, about distributors, or the prices, terms and conditions of sale agreed upon by you and any distributor.
