CodeWarrior for 56800 Digital Signal Controller v11.2
CW-DSC 接收通知
Our CodeWarrior® for Microcontrollers v11.2 integrates the development tools for the 56800 Digital Signal Controller (DSC) based on the Eclipse open development platform. The modular installer is used for this tool, however users only select DSC architectures during the installation.
软件详情
Features
- Eclipse IDE 4.2.2 and CDT 8.1.1
- Unlimited assembler
- C/C++ compiler and debugger
- Integrated flash programmer
- Full-chip simulation for Digital Signal Controller derivatives
- Processor Expert® software and components
- Processor Expert component development environment
- Kernel-aware debug
支持的器件
- MC56F80xxx: 带集成FPU和三角数学引擎的DSC，带OPAMP和正交解码器
- MC56F84xxx: 数字信号控制器
- MC56F82xxx: MC56F82xxx: MC56F826xx和MC56F827xx数字信号控制器
- MC56F81xxx: 高达100MHz的数字信号控制器，带DSASS和运算放大器
系统需求
- 2.6GHz Pentium® compatible processor or better
- 4GB RAM
- 20GB (When installing full product or updates for all architectures)
- 400MB on Windows system disk
- DVD drive for installation
- USB port for communications with target hardware
- Ethernet port for communications with target hardware (optional)
产品规格
- Host platforms
- Microsoft Windows 10 32-bit and 64-bit (Home Premium Edition and Professional Edition)
- Language support
- Assembly
- C/C ++
- Build tools output formats:
- ELF/DWARF 2.0
- NXP S-Record (previously Motorola S19 files)
Host Target Interfaces
- Open Source BDM
- Open Source JTAG
- OpenSDA
- CodeWarrior USB TAP
- CodeWarrior Ethernet TAP
- Cyclone MAX (P&E Microcomputer Systems)
- Cyclone PRO (P&E Microcomputer Systems)
- Cyclone Universal [FX] (P&E Microcomputer Systems)
- USB BDM Multilink (P&E Microcomputer Systems)
- USB Multilink PPCNEXUS (P&E Microcomputer Systems)
- USB Multilink Universal [FX] (P&E Microcomputer Systems)
- Tracelink (P&E Microcomputer Systems)
下载
2 下载
-
开发IDE和生成工具
CodeWarrior for DSC v11.2
-
软件开发资源
CodeWarrior for DSC v11.2 SP1
注意: 推荐在电脑端下载软件，体验更佳。
