The MC33389 is a monolithic integrated circuit combining functions frequently used in microcontroller based systems. The MC33389 includes two internal low drop 5.0 V regulators with current limit, over temperature pre-warning, and reset to provide power for CAN and the MCU plus other peripherals. MC33389 has normal, standby, and sleep modes, an internally switched high-side power supply voltage output with three wake-up inputs, programmable window Watch-Dog, Interrupt, Reset, fault tolerant low speed CAN transceiver for module-to-module communication, and SPI input control. The combination is an economical solution for providing power, low speed fault tolerant communication, and control needed for MCU based systems.
MC33389 removed from active portfolio. Possible Replacement Part: None
