Matched dual high-performance low-voltage operational amplifier[NE5232_SA5232_AU5232]
设计文件
收到完整的详细信息。 请参阅产品足迹及更多信息 电子CAD文件.
Matched dual high-performance low-voltage operational amplifier
- 本页面包含有关样品阶段产品的信息。此处的规格和信息如有更改，恕不另行通知。如需了解其他信息，请联系支持人员或您的销售代表。
The NE/SA/AU5232 is a matched, low voltage, high performance dual operational amplifier. Among its input and output characteristics is the capability for both input and output rail-to-rail operation, particularly critical in low voltage applications. The output swings to less than 50 mV of both rails across the entire power supply range. The NE/SA/AU5232 is capable of delivering 5.5 V peak-to-peak across a 600 Ω load and will typically draw only 700 uA per amplifier. The bandwidth is 2.5 MHz and the 1 pct settling time is 1.4 us.
