i.MX RT1160评估套件

MIMXRT1160-EVK

滚动图片以放大

产品详情

选择区域:

支持的器件

处理器和微控制器

i.MX RT跨界微控制器

特征

Processor

  • MIMXRT1166DVM6A
  • 600 MHz Arm® Cortex®-M7 core
  • 240 MHz Arm® Cortex®-M4 core

Board Memory

  • 512 Mbit SDRAM memory
  • 512 Mbit Octal Flash
  • 128 Mbit QSPI Flash
  • TF socket for SD card

Connectivity

  • 2x Micro-USB OTG connectors
  • Ethernet (10/100/1000M) connector
  • Ethernet (10/100M) connector
  • Optional NXP WiFi and Wifi + Bluetooth add-on boards (SDIO or M.2 based)
  • CAN Transcievers

Audio

  • Stereo Audio codec
  • 4-Pole Audio Headphone Jack
  • External Speaker connection
  • Microphone (Analog and Digital)

Debug Capabilities

  • Arm Cortex and 0.1" SWD/JTAG debug connectors
  • On-board HS USB debugger with VCOM
  • Options for OpenSDA, LPC-Link2 or SEGGER J-Link debug firmware
  • Optional SWO support (LPC-Link2 and J-Link firmware)
  • Optional drag-drop programming (OpenSDA firmware)

Expansion Connectors

  • Arduino UNO R3 interface
  • FRDM Motor control interface

Sensors

  • MIPI Camera Sensor connector

User Interface

  • MIPI LCD connector

购买选项

  • CNY998.37
  • 数量为 1
    • 供货状态: 缺货
Buy from NXP从代理商处购买

设计资源

选择区域:

文档

快速参考 文档类别.

1-5 / 10 文件

展开

设计文件

1 设计文件

软件

1-5 / 6 软件文件

展开

请注意: 推荐在电脑端下载软件,体验更佳。

培训
